RF-Lambda RFST20G40K Coaxial Termination | 20W, DC-40 GHz, 2.92mm

The RF-Lambda RFST20G40K is a high-performance coaxial fixed termination designed for demanding RF and microwave applications. This unit provides a reliable 50Ω load for your system, with a wide frequency range from DC to 40 GHz. It is engineered to handle up to 20 watts of average power and features a 2.92mm connector. Its robust design and high-quality construction make it ideal for use in test and measurement labs, military and aerospace systems, and a variety of other high-frequency applications.

Key Features

• High-Power Handling: Capable of handling an average power of 20W and a peak power of 0.2 kW, ensuring durability and reliability in high-power systems.

• Ultra-Wide Frequency Range: Operates from DC to 40 GHz, making it a versatile component for a broad spectrum of applications.

• Low VSWR: Features a low Voltage Standing Wave Ratio (VSWR) of 1.20:1 to 1.35:1, which minimizes signal reflection and maximizes power transfer.

• 2.92mm Connector: Equipped with a 2.92mm Male connector, ensuring a secure and high-frequency connection.

• Durable Construction: Built with a black epoxy enamel finish on the body, it is designed for a wide operating temperature range of -50°C to +120°C.



This termination is a critical component for protecting sensitive RF equipment and for use in calibration and measurement setups. Whether you are a system integrator, a test engineer, or a research professional, the RF-Lambda RFST20G40K provides the performance and reliability you need.
