FUJITSU Part# JY-5H-K-UL (LOT OF 25) General Purpose Power Relay

Product Attribute

Attribute Value

Manufacturer:

Fujitsu

Product Category:

General Purpose Relays

RoHS:

 Details

REACH - SVHC:

Details

Product:

Power Relays

Type:

High Sensitivity

Coil Voltage:

5 VDC

Relay Contact Form:

1 Form A (SPST-NO)

Contact Current Rating:

5 A

Contact Termination:

Solder Pin

Mounting Style:

Through Hole

Switching Voltage:

250 VAC, 150 VDC

Coil Termination:

Solder Pin

Coil Type:

Non-Latching

Coil Resistance:

125 Ohms

Contact Material:

Silver Cadmium Oxide (AgCdO)

Series:

JY

Length:

20 mm

Width:

9.8 mm

Height:

12.8 mm

Packaging:

Tube

Brand:

Fujitsu

Contact Form:

SPST (1 Form A)

Power Consumption:

200 mW

Product Type:

General Purpose Relays
